Specifications
Type ATX12V v2.4
Efficiency Meet 80 PLUS Bronze efficiency
Power Factor Correction APFC with PF value of 0.99
Support Motherboard RGB Sync Connectors 5V 3-pin Addressable (Digital) LED RGB Header Only
Output
AC Input 100-240V, 4.5-9.5A, 47-63Hz
DC Output +3.3V +5V +12V -12V +5Vsb
Max. Output Current 20A 20A 47A 0.3A 2.5A
Max. Output Power 120W 564W 3.6W 12.5W
Total Power 600W
Protection
Protection OVP/ UVP/ OPP/ SCP/ SP/ ICP
Connector
Main Power 1 (20+4 Pin)
CPU 1 (4+4 Pin)
PCI-E 2 (6+2 Pin)
SATA 5 (5 Pin)
Molex 2 (4 Pin)
Floppy 1 (4 Pin)
Note: Actual products may vary due to product enhancement and are mainly based on specifications on package.
