Specifications
Type ATX12V v2.4
Efficiency Meet 80 PLUS Gold Efficiency
Power Factor Correction APFC with PF value of 0.99
Support Motherboard RGB Sync Connectors 5V 3-pin Addressable (Digital) LED RGB Header Only
Support C6/C7 power state Yes
Output
AC Input 100-240V, 10A, 47-63Hz
DC Output +3.3V +5V +12V -12V +5Vsb
Max. Output Current 20A 20A 62.5A 0.3A 2.5A
Max. Output Power 100W 750W 3.6W 12.5W
Total Power 750W
Protection
Protection OVP/ UVP/ OPP/ OCP/ SCP/ SP/ ICP
Connector
Main Power 1 (20+4 Pin)
CPU 2 (4+4 Pin)
PCI-E 4 (6+2 Pin)
SATA 8 (5 Pin)
Molex 3 (4 Pin)
Floppy 1 (4 Pin)
Note: Actual products may vary due to product enhancement and are mainly based on specifications on package.
