PoE budget calculations are based on laboratory testing. Actual PoE power budget will vary as a result of client limitations and environmental factors.
8 PoE + Ports (65 Budget) for Network Deployment
Ports1-8support PoE+, and each PoE+ port supports a maximum of 30W and is compliant with the 802.3 af/at Powered Devices. Also provide 2 ports without PoE+ one for internet and NVR use. The total 65W PoE power budget for the 8xPoE+ports enables a variety of uses, including surveillance for offices.
The speed of the ports in extend mode will downgrade to 10Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.
Durable and Silent
MS110GP's durable metal case allows for efficient heat dissipation, excellent signal interference prevention, equipment stability, and long network life.
Traffic Separation
With only one click, isolation mode divides traffic for ports 1-8 to prevent snooping/tampering and isolate broadcast storms for greater protection.
Port Prioritization
Prioritizing the data of specific ports would ensure the high quality of delicate applications, such as voice and video, in crucial business domains.
Plug and Play
MS110P offers auto-negotiation (10/100 M) and automated MDI/MDIX. There is no additional configuration needed. It is simple to use.
PoE Auto Recovery
When a PD stops sending data packets to the switch for an extended length of time, the switch will reboot it automatically.
Long-Rang up to 250m with Extend Mode
Extend Mode increases PoE transmission distance to 250m. MS110GP has 8 long-rang ports with PoE+. Turn on the Extend mode and make it ideal for installing surveillance cameras over wide areas.
